Mach4

  • VistaCNC pendants support Mach4.

  • Files to upgrade P4-S to Mach4.

  • Files to upgrade P2-S to Mach4.

  • Files to upgrade P1A-S to Mach4.

LinuxCNC

  • VistaCNC pendants support LinuxCNC.

  • Models support LinuxCNC: M1, P1A-S, P2-S and P4-S

  • Files to upgrade M1 to LinuxCNC.

  • Files to upgrade P1A-S to  LinuxCNC.

  • Files to upgrade P2-S to LinuxCNC.

  • Files to upgrade P4-S to LinuxCNC.

Mach3

  • iMach3 USB CNC MPG control Pendants are truly Plug 'n Play devices!

  • Work with any Mach3 Screen.

  • Work independently. You can use iMach3 pendant with the keyboard or with another pendant at the same time.

  • Work with parallel port controller, any USB and Ethernet based controllers for metal, wood, plasma and foam cutting applications.

  • 100 step (click) per turn, high precision MPG with stainless steel encoder disk.



          iMachIII P2-S pendant



    LCD display with Backlight.

    Large E-STOP button.

    Jogging + control



          iMachIII P4-S pendant



    LCD display with Backlight.

    Large E-STOP button.

    6 axis selections.

    6 MPG modes.

    3 user definable buttons.





          iMachIII P1A-S pendant



     LCD display with Backlight.

    Large E-STOP button.

    Packed with all the jogging functions.







             iMachIII P1A pendant

    Cost effective Pendant.

   Packed with all the jogging functions.











                                    iMachIII P3A pendant

     Small size buttons with LEDs for each operation.

    Micro switch for Axis selection

    Predefined number quick selection for Step Size, Feed rate, Spindle speed and Slow Jog Rate.













    iMachIII M1 pendant



    100 steps MPG.

    3 jogging modes + 3 MPG modes

    5 control buttons + 3 function buttons.









          iMachIII M2 pendant



    4 axis Step and Continuous jogging.

    Quick jogging mode change.

    Step size and jog rate indicators.



                iMachIII Spindle Tachometer

     Integrated Reflective Optical Sensor.

     Self powered USB connection.





                                   EE Box

     Provide an isolated Normally-Close signal

      through E-Stop button in the pendant.
